Efficiency Double Color Paper Tube Machine For Packing Single Drinking Straw

Product Categories
WENZHOU WEIXIN MACHINERY CO.,LTD
Contact Now

Efficiency Double Color Paper Tube Machine For Packing Single Drinking Straw

  • 1
  • 2

Brand Name : WEIXIN

Model Number : WXZGJ-50

Certification : CE

Place of Origin : Zhejiang,China(Mainland)

MOQ : 1 Set

Price : Negotiation

Supply Ability : 50 Set /Month

Delivery Time : 15 working days

Packaging Details : wooden pallet

Diameter : 4.7-12 mm

Paper layer : 3 layer

Thickness of paper : 120 gsm & 60 gsm

Speed : 35-40m/min

Gluing way : Single and double

Operator : 1-2 person

Power : 380V/3 Phase/50HZ

Dimension : 3500*1500*1200mm

Weight of machine : 1300 Kgs

After-sales service : Engineers available to service machinery overseas

Contact Now

Efficiency Double Color Paper Tube Machine For Packing Single Drinking Straw

Feature

1.Adopt human-machine operation interface,more convenient for operation

2.Paper reeling stand ,slitting rolls are easily pplaced into reel stand by electric lifting device

3.Choose Single or double gule coating unit

4.spiral winding part ,hanging-type operation panel,specialized operation system,Belt tension device(hand-wheel driven)

5.Multi-knife system in -line cutting unit controlled encoder,cutting final paper tube directly

Technical Parameters

Technical Parameter Control System
Paper Layer 3 layers Motor 3.0kw (1.5kw * 2pcs)
Inner Diameter 4.7-12mm Motion Controller Panel Master
Wall Thickness 0.5-2mm Operating Panel Panel Master
Stable Speed 35-40m/min. Language English
Winding Nose Two noses single belt Inverter 3.7kw Schneider
Machine & parts Painting Electric Components Schneider
Length fixing Encoder Pneumatic Components Jingwei
Speed Control By Inverter Servo Motor Schneider
Cutting System Multi-blades; 5 pcs online Servo Driver Schneider
Synchronism tracking cutting system Servo motor synchronism tracking Screw Rod Shangyin
Slider Shangyin
Paper straw collecting Manually Bearing Haerbin
Operator 1-2 person Configuration
Working Air Pressure 0.6Mpa Paper Reel Stand 3 Layers
Power Supply 380V / 3phases / 50 Hz 6KW Gluing Unit 3 Layers
Measurement & Weight Belt 5 Pieces
Measurement 3500*1500*1200mm Mandrel Shaft 2 Pieces
Working Space 7000*5000mm Extra blades 5 Pieces
Weight 1300kgs Useful Tool 1 Set
Paper Straw Samples
